TXP-20: Built for Competition and Play
The TXP-20 is designed for riders aged 7 to 10 who are ready to take on more technical terrain or step into junior trials competition. With a powerful 1200W motor paired to a high-capacity 50V, 20Ah lithium battery, it delivers extended range, confident off-road torque, and a top speed of up to 22mph. Triumph’s expert tuning ensures smooth, progressive throttle mapping across four rider modes, whether focused on trail exploration or trials precision.
Suspension performance takes a major step up with a 125mm air-sprung front fork and a 120mm rear monoshock, both featuring rebound adjustment for fine-tuning. The larger steel chassis, with a 1085mm wheelbase, offers stability and control, while overall weight starts at just 40.7kg depending on configuration. Stopping power is equally impressive, with front and rear 180mm dual-piston hydraulic discs providing consistent, reliable braking.
Tailored ergonomics make the TXP-20 adaptable to growing riders, with a seat height of 525mm in Trials mode or 700mm in Explore mode, plus 255mm of ground clearance for added versatility. Like the rest of the TXP range, it features Triumph’s modular riding setup, allowing quick adjustments between seated and standing positions.
For added assurance, the TXP-20 is equipped with diagnostic-ready electronics, capable of displaying system fault codes and service alerts for straightforward troubleshooting and easy maintenance. Combining competition-ready performance with rider-friendly adaptability, the TXP-20 is the perfect machine for young riders who are ready to play harder and push further.
Category |
Specification |
Engine |
Electric Motor 1200w 50v brushless direct current, with encoder position sensor, maximum speed 22 mph
|
Displacement |
N/A |
Power |
1200W |
Torque |
N/A |
Fuel System |
Electric, battery powered |
Transmission |
Direct drive, single speed |
Final Drive |
Chain |
Suspension (Front) |
Air spring fork, rebound adjustment, 125 mm wheel travel
|
Suspension (Rear) |
Monoshock air spring, rebound adjustment, 120 mm wheel travel
|
Brakes (Front) |
180 mm front rotor, hydraulic 2 piston disc brakes, ball ended levers with reach adjustment
|
Brakes (Rear) |
180 mm solid rear rotor, hydraulic 2 piston disc brakes, ball ended levers with reach adjustment, with guard
|
Wheels |
|
Tyres |
20 x 2.50 in, trials pattern
14 x 3.25 in, trials pattern motorcycle construction
|
Seat Height |
700 mm ± 10 mm (525 mm with included seat insert fitted, see product images).
|
Wheelbase |
|
Rake / Trail |
N/A |
Tank Capacity / Range |
Sealed 50V, 20AH Lithium-ion battery pack with LED status indicator
|
Weight (Wet) |
40.7kg |
Display |
Battery SOC, Fault codes, Thermal warning
|
Service Interval |
N/A |
